A new generation of top hung and pivot windows with two independently opening mechanisms of the sash - FAKRO

Top hung and pivot window preSelect FPP-V P2

  • Two independently opening mechanisms of the sash: external and pivot opening
  • The external opening function allows the sash to be undone in any position from 0 to 35 degrees; pivot function allows the sash to be rotated up to 180 degrees
  • The external opening function permits an easy approach to the window and providing a extensive view to the outside. A groundbreaking hardware system assures full sash stability in both opening function. Opening technique can be switched using the preSelect sliding switch located in the middle of the frame, available when the window is open

Top hung and pivot window preSelect FPP-V P2



Top hung and pivot window preSelect
  • Easy operation by the use of handle positioned on the lower part of the sash. Handle equipped with two stage micro-ventilation
  • FPP-V P2 window is armed with an automatic ventilator V40P delivers the best amount of air into the room. V40P automatic air-inlet guarantees a healthy micro-climate in the attic and saves energy
  • Easy cleaning of the outer pane and easy awning blind installation - thanks to the bolt blocking the sash rotated through 180 degrees





Flashings Accessories

A new generation of top hung and pivot windows with two independently opening mechanisms of the sash - FAKROthermoPro technology as standard

System topSafeTopsafe® system of burglary protection as standard



Where to buy? Contact our Distributor Catalogs and Brochures

  • FPP-V preSelect


    • Air inlet V40Pautomatic air inlet V40P
    • Highest quality pine woodhighest quality pine wood, glued in layers, vacuum impregnated
    • Wood painted twice with ecological acrylic lacquerwood painted twice with ecological acrylic lacquer in natural colour
    FPP-V P2 preSelect
    • 1.3 W/m²K window U-value 1.0 W/m²K glazing U-value 35 (-1, -3) dB acoustic insulation Rw 4H-15-33.1 glazing unit argon inert gas filled panes + external glass toughened V40P air inlet type up to 49m³/h air inlet air flow twice varnishing four seals + multi-point opening Elegant handle

FPP-V P2 available sizes



Size   16 04 05 06
Rough opening (WxR) in. 22 x 46⅞ 26¼ x 46⅞ 31 x 39 31 x 46⅞
Outside frame (SxL) in. 21½ x 46½ 25⅞ x 46½ 30¼ x 38⅝ 30¼ x 46½
Daylight area (glass)

sq.ft

m2

5.38

0.50

6.67

0.62

6.67

0.62

8.07

0.75



Size   07 80 10 12 17
Rough opening (WxR) in. 31 x 55½ 37¼ x 63½ 45¼ x 46⅞ 53 x 39 53 x 55½
Outside frame (SxL) in 30¼ x 55 36⅞ x 63 44¾ x 46½ 52⅝ x 38⅝ 52⅝ x 55⅛
Daylight area (glass)

sq.ft

m2

9.80

0.91

13.89

1.29

12.38

1.15

12.06

1.12

17.65

1.64
