Metal attic ladders
-
LMS
-
plastic ends
-
beige hatch - lock
-
peripheral gasket
-
non-slip steps
-
additional accessories available
-
fully assembled and ready for quick installation in the ceiling
-
2-year warranty
LMS Heavy-Duty Insulated
- 350 lbs maximum loading 0,19 BTU/hft²F loft ladder hatch U-value 1 1/8 insulation thickness 1 3/8 hatch thickness ANSI 14.9.2004 norm requirements 5.2 attic ladder R-value
The LMS is a heavy-duty attic ladder that folds in three sections. The lid is insulated and a seal lines the perimeter of the frame.
Click below to enlarge the image.
-
-
LMB
-
plastic ends
-
insulated door ready for paint
-
non-slip steps
-
handrail
-
additional accessories available
-
1 year warranty
LMB
- 350 lbs maximum loading 1 hatch thickness 3.7 attic ladder R-value
The LMB is a basic insulated metal attic ladder. It features standard accessories for the user to access an used space in the attic all while equipped with a handrail, insulated door and a weather seal gasket to reduce heat loss.
Click below to enlarge the image
-
-
LMP
-
plastic ends
-
white hatch
-
peripheral seal
-
non-slip treads
-
ladder unloading mechanism, built in handrail
-
possibility of installing additional accessories
-
fully assembled and ready for quick installation in the ceiling
-
2-year warranty
LMP 12-Foot Insulated
- 350 lbs maximum loading 0,19 BTU/hft²F loft ladder hatch U-value 1 1/8 insulation thickness 1 3/8 hatch thickness Accordance with ANSI 14.9.2004 norm requirements 5.2 attic ladder R-value
The LMP is a metal, 3-section folding attic ladder designed for high spaces, up to 12’.
Click below to enlarge the image
-
-
LML Lux
-
telescopic stile ends
-
white hatch - plastic catch
-
finishing lining slats
-
peripheral gasket
-
non-slip steps
-
ladder unloading mechanism, built in handrail
-
quick installation in the ceiling - installation brackets
-
additional accessories available
-
fully assembled and ready for quick installation in the ceiling
-
2 year warranty
LML Lux Insulated
- 300 lbs maximum loading R-value 5.2 loft ladder hatch U-value 1 1/8 insulation thickness 1 3/8 hatch thickness EN 14975 norm requirements
The LML is a metal, three-section folding attic ladder with piston-assisted unfolding. Adjusting the ladder length to the ceiling height is simplified with adjustable stile ends.
Click below to enlarge the image.
-
